49070401 Abox-i 040 SB-L
Код товара: 89103
Ціна за запитом
Junction box, Type of protection IP65, max. 4², Impact strength IK08, Protection class II, Ui 690V AC, DLG, DNV, VDE, Halogen free
| Виробник |
|---|
Junction box, protection class IP65, nominal cross-section 4mm², Ui=690 V AC, certified by VDE (DIN EN 60670-1/-22 (VDE 0606-1/-22)), DLG (Ammonia resistance), DNV (Class: Ships and Offshore Installations), self-sealing, soft insertion membranes, M20, sealing range 2-16mm, (1 rear, 7 side), internal fixing points, for installations in industrial environments and protected outdoor areas, grey, with red cover, without terminals, for identifying circuits for safety lighting
Dimensions: 93 x 93 x 55mm
International product number (GTIN): 4013902894499
Universal product code (UPC):
Alternative product number:
Product ID of the manufacturer: 49070401
Manufacturer type description: Abox-i 040 SB-L
Ключові слова: abx, abx, aox, aox, DNV, DNV, maritim, maritime, marine, marine
Special product status:
Classification system: ETIM-9.0
Group reference: EC002600
Посилання
Страница продукта
Link to FAQ
Link to Application example
Link to Download
Link to Technical data sheet
Link to Sales brochure
Link to REACH information
Link to Product page
Dimensioned drawing
Link to Product note
Link to Siemens support portal
Circuit diagram
